EnGenius ECS2528FP Cloud 24-Port 410W POE+( 8 x 2.5Gb, 16 x Gigabit), 4 x 10G SFP+
เพิ่มเมื่อ: 2025-04-28 16:11:35.0
แก้ไขล่าสุด: 2025-04-28 16:12:03.0
เบอร์โทรติดต่อ: 062-5193997 , 02-4582949
อีเมลล์: krieng.nt@gmail.comMulti-Gigabit Switch (สวิตซ์) EnGenius ECS2528FP Cloud 24-Port 410W POE+( 8 x 2.5Gb, 16 x Gigabit), 4 x 10G SFP+
EnGenius ECS2528FP
Multi-Gigabit Switch (สวิตซ์) EnGenius ECS2528FP Cloud 24-Port 410W POE+( 8 x 2.5Gb, 16 x Gigabit), 4 x 10G SFP+
EnGenius Cloud Managed Layer 2+ Multi-Gigabit 2.5Gb Switch, ECS2528FP, provides SMBs with an easy-to-use and cost-effective network solution. With its 16-Port Gigabit PoE+ and 8-Port 2.5G PoE+ as well as 4-Port 10G SFP+ uplink with 410W budget, it ensures high-speed data transfer for bandwidth-intensive applications. With zero-touch provisioning and centralized cloud management, it simplifies network management and saves time.
- 8x 2.5G PoE+ Ports to unleash elevated speeds for NAS, workstations, or WiFi 6 APs
- 16x Gigabit PoE+ ports for a wide range of network devices such as IP cameras, VoIP phones, workstations, and more
- 4x Dual-Speed 10G SFP+ (fiber) uplink ports to high-speed NAS and servers for a high-performance network
- 24x 802.3af/at PoE+ ports with 410W power budget
- Zero-touch provisioning, centralized cloud management, and visualized monitoring
- Hybrid cloud switch supports flexible management options such as EnGenius Cloud or standalone
- Robust security that supports Port-based / MAC-based ACL Storm control, DHCP Snooping, DOS Attack Prevention, 802.1X & RADIUS Authentication, and more
- Optimized for quality voice and video traffic with Voice-VLAN feature
- PoE Extended Mode: Extend PoE Ethernet cable deploying range up to 250 meters
- PD Lifeguard: Real-time detecting and auto-reboot PoE power for failed camera
- Continuous PoE Power: Steady supply of PoE power for the camera during switch upgrades
Technical Specifications
Port Standards :
802.3u 100Base-TX Ethernet
802.3ab 1000Base-T Ethernet
802.3bz 2.5G/5GBase-T Ethernet
802.3x Full-Duplex Flow Control
Network Ports :
16×10/100/1000 Mbps Ports
8×100/1000/2500 Mbps Ports
4x SFP+ Ports
Switching Capacity : 152Gbps
SDRAM : 512MB
Flash Memory : 128MB
PoE Capable Ports : 1-24
Total PoE Budget : 410w
Power Source : 100 ~ 240VAC, 50-60Hz
Physical Interface
System Indicators :
Power LED
Fault LED
PoE Max LED
LAN Mode LED
PoE Mode LED
Port Indicators :
Link/Activity/Speed (per Ethernet port)
Link/Activity/Speed (per SFP slot)
L2 Features
Network Management :
EnGenius Cloud
Local Web GUI
MAC Address Table : 16K
Jumbo frame size : 10K
Multicast Group : Max 256 groups
MLD Snooping : MLD Snooping: v1
QoS-number of Priority Queues Supported/
Queue 8
QoS Trust Mode :
Cos/802.1p
DSCP
CoS/802.1p-DSCP
Scheduling Mechanism : Strict / WRR/ Strict + WRR
Bandwidth Control : Port-based bandwidth control (Ingress/Egress)
Port Security : Max. 256 Entries
Access Control List (ACL) :
MAC Based ACL
IPv4/IPv6 Based ACL
ACL Binding
Web Graphical User Interface (GUI) :
HTTP IPv4 / IPv6
HTTPS IPv4 / IPv6
SNMP : SNMP v1/v2c/v3 Support
RMON : RMON 1,2,3,9
System Time : ime Setting/Daylight saving
Common L2 Features :
802.1D Spanning Tree
802.1w Rapid Spanning Tree
802.1S Rapid Spanning Tree
Loopback Detection
Multicast Filitering
IGMP Snooping
802.1Q VLAN tagging
802.3x flow control
802.3ad Link Aggregation
IPv4 DHCP Relay
IPv4 DHCP Snooping
IPv4 DHCP Snooping Source MAC Address Check-up
ARP Packet Validation (additional validation checks)
Voice VLAN
Port-based VLAN
CoS Mapping
802. 1X Radius Authentication Protocol
IPv4 Settings/ IPv6 Settings
IEEE 802. 3az Energy Efficeient Ethernet (EEE)
Command Line Interface (CLI)
SSH Server
Telnet Server
TFTP Client
Configuration Upgrade/ Backup
Simple Network Time Protocol (SNTP)
SYSLOG
